ZHJ-260 Automatic Carton Machine

ZHJ-260

This machine is suitable for packing blisters, tubes, ampoules and other related objects into boxes. It can be run continuously and the highest speed can up to 260boxs/min. It has advantages of high packing efficiency and good quality, and is high-tech product with structure of mechanical-electrical integration. This machine can fold leaflet, open box, insert blister into box, emboss batch number and then close or seal automatically. It adopts frequency inverter to adjust speed, human machine interface to operate, PLC to control, and photoelectric to supervise and control each station. So that once something unexpected happens speed its running, it will stop and display the reasons automatically, which can solve the troubles in time. This machine can be used separately, and also can be linked to other machine to be a production line. Note: this machine can also equip hot melt glue device to do hot melt glue sealing for boxes.

Contact Us
ZHJ-260 Automatic Carton Machine
ZHJ-260 Automatic Carton Machine
ZHJ-260 Automatic Carton Machine
ZHJ-260 Automatic Carton Machine
ZHJ-260 Automatic Carton Machine
ZHJ-260 Automatic Carton Machine

This machine is suitable for packing blisters, tubes, ampoules and other related objects into boxes. It can be run continuously and the highest speed can up to 260boxs/min. It has advantages of high packing efficiency and good quality, and is high-tech product with structure of mechanical-electrical integration. This machine can fold leaflet, open box, insert blister into box, emboss batch number and then close or seal automatically. It adopts frequency inverter to adjust speed, human machine interface to operate, PLC to control, and photoelectric to supervise and control each station. So that once something unexpected happens speed its running, it will stop and display the reasons automatically, which can solve the troubles in time. This machine can be used separately, and also can be linked to other machine to be a production line. Note: this machine can also equip hot melt glue device to do hot melt glue sealing for boxes.

Technical Parameters

model

ZHJ-260

Production capacity (box/min)

80-260

Max size of box (mm)(l*w*h)

200*80*70

Min size of box (mm)(l*w*h)

65*25*15

Specification of box

250-300g/m2

Max size of leaflet (l*w)

260*180mm

Min size of leaflet (l*w)

110*100mm

Specification of leaflet

55-65g/m2

Volume of air consumption

20m2/h

Total power (Kw)

6.9

Power supply

380v 50hz

Overall dimension (l*w*h)

4500*1460*1800

Weight (kg)

3000


Can I get samples from your factory?

No, Our factory will produce equipment according to the bottles and caps provided by customers.

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

What’s the delivery time ?

Pattern needs 30-60 days.

What is the standard of package?

Export standard package or special package according to customer requirement.

Do you accept OEM business?

Yes, we are OEM supplier.

What kind of certificate you have ?

We have ISO9001, CE,SGS
