ZHTB60 Tube Labeling Machine

ZHTB60

The machine adopts Germany advanced technology and high-powered components------ small inertia servo motor to reach the real perfect labeling. The system carries out high response and highly reliability by the professional approved program controller of German Siemens CO. and Mitsubishi servo system, it carries out communication between machine and man by touch screen, the precision of the main machine can up to 0.01 meter per min during the process of the sending label control.

Contact Us
ZHTB60 Tube Labeling Machine
ZHTB60 Tube Labeling Machine
ZHTB60 Tube Labeling Machine
ZHTB60 Tube Labeling Machine
ZHTB60 Tube Labeling Machine
ZHTB60 Tube Labeling Machine

The machine adopts Germany advanced technology and high-powered components------ small inertia servo motor to reach the real perfect labeling. The system carries out high response and highly reliability by the professional approved program controller of German Siemens CO. and Mitsubishi servo system, it carries out communication between machine and man by touch screen, the precision of the main machine can up to 0.01 meter per min during the process of the sending label control.

Technical Parameters
Labeling speed 40-60 tubes/min.
Labeling accuracy ±0.5mm
Label diameter (Max.) 350mm
Label width (Max.) 200mm
Tube diameter (Max.) 65mm
Tube diameter (Min.) 19mm
Tube length (Max.) 220mm
Label Reel Core Diameter 76.2mm
Power 220V 50Hz 3000W
Weight 300kg




Can I get samples from your factory?

No, Our factory will produce equipment according to the bottles and caps provided by customers.

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

What’s the delivery time ?

Pattern needs 30-60 days.

What is the standard of package?

Export standard package or special package according to customer requirement.

Do you accept OEM business?

Yes, we are OEM supplier.

What kind of certificate you have ?

We have ISO9001, CE,SGS

Food Products & Beverages

Zungwan Intelligent focus on manufacturing sanitary filling systems to meet the needs of foods and beverages industry. The food filling machines and beverage filling machines are available for applications using viscous products, but the bottling machinery can be easily and thoroughly cleaned. Clean-in-place systems can also be included to assist the operator in cleaning the inline filler. All filling machines are designed for easy setup, simple changeover, minimal downtime for maintenance & cleaning, and maximum versatility.

Cosmetic & Personal Care Products

It's important to the best-suited cosmetic filling machine for your packaging line when it comes to liquids about these industries of personal care, health and beauty. The filling equipments will be ensured working effectively for many years by using durable machines and special designs to handle these types of liquids products.

Pharmaceutical Filling Machines

Our pharmaceutical filling machine ensures a high degree of compatibility with the chemicals you process, adapting to the viscosity, acidity, and foaming properties of different pharmaceuticals. And they are easy to clean to maintain efficiency. Our product range is complete, so whether you just need a single machine or have to build a filling and packaging line from scratch, Zungwan can provide you with the corresponding results.

Household & Industrial Cleaners

The automatic filling machines can function safely and efficiently no matter the viscosity, acidity or foaming properties. Different corrosion and foaming properties would impact the type of bottle filling machines. Some chemicals may be volatile, or cause corrosion on your automatic filling equipment. We provided the best janitorial product filling systems for you, ensuring the compatibility with the chemical products.
