ZHTBW01 Horizontal Around Bottle Labeling Machine

ZHSP-100Y

It is used for automatic labeling and printing different bottles in pharmacy industry such as ampoule bottle, vial bottle, oral bottle and so on.

Contact Us
ZHTBW01 Horizontal Around Bottle Labeling Machine
ZHTBW01 Horizontal Around Bottle Labeling Machine
ZHTBW01 Horizontal Around Bottle Labeling Machine
ZHTBW01 Horizontal Around Bottle Labeling Machine
ZHTBW01 Horizontal Around Bottle Labeling Machine

        It is used for automatic labeling and printing different bottles in pharmacy industry such as ampoule bottle, vial bottle, oral bottle and so on.

Features
  • Intuitive and user friendly touch screen makes the operation easy.
  • Intelligent label control and error warning functions.
  • Unique bottle breaking proof technology.
  • World renowned brands of electrical components ensures the stable and reliable performance.
  • Optional coder or ink jet printer realize the information printing while labeling.
  • Use bottle dialing device to separate the bottles. It only needs to change the bottle dialing roller when bottles are changed. One machine can be used for different sizes of bottles.
  • Roller chain conveyor ensures accurate and stable labeling.
Technical Parameters
Labeling speed 200-300bottle/min. (Varies with the different sizes of substrates or label)
Labeling accuracy 0.5mm (Excluding the error of substrate and label)
Bottle diameter 0-22mm OR 18-30mm
Power and power supply AC220V 5% 50Hz 1200W
Dimensions 1800mm(L) x700mm(W)x1500mm(H)




Can I get samples from your factory?

No, Our factory will produce equipment according to the bottles and caps provided by customers.

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

What’s the delivery time ?

Pattern needs 30-60 days.

What is the standard of package?

Export standard package or special package according to customer requirement.

Do you accept OEM business?

Yes, we are OEM supplier.

What kind of certificate you have ?

We have ISO9001, CE,SGS

Food Products & Beverages

Zungwan Intelligent focus on manufacturing sanitary filling systems to meet the needs of foods and beverages industry. The food filling machines and beverage filling machines are available for applications using viscous products, but the bottling machinery can be easily and thoroughly cleaned. Clean-in-place systems can also be included to assist the operator in cleaning the inline filler. All filling machines are designed for easy setup, simple changeover, minimal downtime for maintenance & cleaning, and maximum versatility.

Cosmetic & Personal Care Products

It's important to the best-suited cosmetic filling machine for your packaging line when it comes to liquids about these industries of personal care, health and beauty. The filling equipments will be ensured working effectively for many years by using durable machines and special designs to handle these types of liquids products.

Pharmaceutical Filling Machines

Our pharmaceutical filling machine ensures a high degree of compatibility with the chemicals you process, adapting to the viscosity, acidity, and foaming properties of different pharmaceuticals. And they are easy to clean to maintain efficiency. Our product range is complete, so whether you just need a single machine or have to build a filling and packaging line from scratch, Zungwan can provide you with the corresponding results.

Household & Industrial Cleaners

The automatic filling machines can function safely and efficiently no matter the viscosity, acidity or foaming properties. Different corrosion and foaming properties would impact the type of bottle filling machines. Some chemicals may be volatile, or cause corrosion on your automatic filling equipment. We provided the best janitorial product filling systems for you, ensuring the compatibility with the chemical products.
