Name: ZHBS-1928M Inline Filling Capping Line
Brand: Zungwan
SKU: 00048
Rating: 4.1 (74 reviews)

ZHBS-1928M Inline Filling Capping Line

ZHBS-1928M

This type machine is suitable for the filling of 100g to 5000g liquid filling. It can finish a series of operations automatically such as counting bottle, bottles inlet ,weight filling and bottles outlet.

This machine is the newest filling machine. It is characterized by large productivity, high automation, weight filling and high precision, especial suitable for SL, EC, SC, Edible oil, lubrication. This filler is an ideal choice for foodstuff, pharmacy cosmetic and chemical, pesticide factories.

Major Characteristics

This machine adopts PLC,touch screen control panel, convenient to adjust.
Each filling head has the weigh and feedback system. Each filling head can be regulated and micro adjusted.
Photoelectric sensor ,approximate switch and other electrics elements are the international famous brand. NO bottle no filling,the main host will trigger the alarm if there is any container blocked.
The whole machine gets GMP standard .It is easy to disassemble ,clean and maintain, and the parts which contact with the filling materials are made of high quality stainless .The whole machine is safe ,environmental,sanitary .It can adapts to various of working places.

Technical Parameters

Type	Heads	Suitable bottles	Capacity(bottle/hour)	Precise	Size of Machine(mm)	Power(kW)	Power source	Air source

DGP-CZ-26X	24	round bottle： height:180-280mm， diameter:Φ80-150mm. drum： height:180-280mm， width:40-80mm， length:80-120mm， neck diameter≥Φ28	1L:5000	1-5L≤±3g	2400×1800×2500	5	AC 220V; 50Hz	0.6MPa	＜Φ18
DGP-CZ-20X	20		1L:4500		2400×1900×2500	5
DGP-CZ-18X	18		1L:3800		2200×1600×2500	4.5
DGP-CZ-16X	16		1L:3000		2200×1500×2500	4
DGP-CZ-12X	12		1L:2400		2000×1300×2500	3.5

ZHBL-1922C PLC Controlled Piston Filling Machine

ZHBL-1916H Intellectual High-viscosity Filler

Can I get samples from your factory?

No, Our factory will produce equipment according to the bottles and caps provided by customers.

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

What’s the delivery time ?

Pattern needs 30-60 days.

What is the standard of package?

Export standard package or special package according to customer requirement.

Do you accept OEM business?

Yes, we are OEM supplier.

What kind of certificate you have ?

We have ISO9001, CE,SGS

Food Products & Beverages

Zungwan Intelligent focus on manufacturing sanitary filling systems to meet the needs of foods and beverages industry. The food filling machines and beverage filling machines are available for applications using viscous products, but the bottling machinery can be easily and thoroughly cleaned. Clean-in-place systems can also be included to assist the operator in cleaning the inline filler. All filling machines are designed for easy setup, simple changeover, minimal downtime for maintenance & cleaning, and maximum versatility.

Cosmetic & Personal Care Products

It's important to the best-suited cosmetic filling machine for your packaging line when it comes to liquids about these industries of personal care, health and beauty. The filling equipments will be ensured working effectively for many years by using durable machines and special designs to handle these types of liquids products.

Pharmaceutical Filling Machines

Our pharmaceutical filling machine ensures a high degree of compatibility with the chemicals you process, adapting to the viscosity, acidity, and foaming properties of different pharmaceuticals. And they are easy to clean to maintain efficiency. Our product range is complete, so whether you just need a single machine or have to build a filling and packaging line from scratch, Zungwan can provide you with the corresponding results.

Household & Industrial Cleaners

The automatic filling machines can function safely and efficiently no matter the viscosity, acidity or foaming properties. Different corrosion and foaming properties would impact the type of bottle filling machines. Some chemicals may be volatile, or cause corrosion on your automatic filling equipment. We provided the best janitorial product filling systems for you, ensuring the compatibility with the chemical products.
