ZHNP-50A Enamel Filling & Plugging And Capping Machine

ZHNP-50A

Nail Polish Filling &Plugging and Capping Machine with functions of automatic filling, loading brush and capping. The filling device adopts bottle positioning mechanism to solve the problem of large size deviation of the nail polish filling glass container that the filling nozzle can not be put into the container.

Contact Us
ZHNP-50A Enamel Filling & Plugging And Capping Machine
ZHNP-50A Enamel Filling & Plugging And Capping Machine
ZHNP-50A Enamel Filling & Plugging And Capping Machine
ZHNP-50A Enamel Filling & Plugging And Capping Machine
ZHNP-50A Enamel Filling & Plugging And Capping Machine
ZHNP-50A Enamel Filling & Plugging And Capping Machine

Brief Introduction

Nail Polish Filling &Plugging and Capping Machine with functions of automatic filling, loading brush and capping. The filling device adopts bottle positioning mechanism to solve the problem of large size deviation of the nail polish filling glass container that the filling nozzle can not be put into the container. The storage bucket uses the way of pressure feeding by separating from the main machine. The volume of the bucket can be customized by customers and place the storage bucket randomly. That alternate use of multiple storage buckets effectively shorten the time for replacement of different materials. Adopt the approach of mechanical arm fetching cap, pre-spin to cover, which solve the problem of  brush poor positioning, and cannot cover .Capping device with a torque adjusting device, capping torque can be adjusted according to customer’s requirement. The whole machine adopts PLC control, with the function of no bottle no filling, no brush no cover, easy operation and adjustment conveniently.

Technical Parameters
Main motor power 0.75KW
Production Capacity 40pcs/min
Filling volume 5-20ml
Air supply pressure 0.6-0.8Mpa
Dimension 2400*1650*1820mm




Can I get samples from your factory?

No, Our factory will produce equipment according to the bottles and caps provided by customers.

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

What’s the delivery time ?

Pattern needs 30-60 days.

What is the standard of package?

Export standard package or special package according to customer requirement.

Do you accept OEM business?

Yes, we are OEM supplier.

What kind of certificate you have ?

We have ISO9001, CE,SGS
